Diagnostic and Calibration Pressure hose overview
Diagnostic and calibration pressure hoses are essential tools in various industries for ensuring the proper functioning of hydraulic systems. These hoses are designed to withstand high pressures and provide reliable connections for pressure testing and calibration. Here are some key points about diagnostic and calibration pressure hoses:
-0.1-6MPa (-1~ +60bar)
1100P04 00 (Transpaency)
1100P04 01(Black)
1100P 04 02 Green
1100P 04 03 Red
1100P04 04 Blue
1100P04 05 Yellow
1100P 04 06 Grey LP: 745
1100P03 00 18
1100P03 04 18 LP: 510
Standard Length ： 1500mm
Out Diameter ： 4mm X 2mm
Medium： Noncorrosive Gases
Thread Style： M20x1.5 Female , M20x1.5 QCD Male
-0.1-40Mpa (-1~ +400bar ) / -0.1-63Mpa (-1~ +630bar )
2020N-012V30 / 2020N-012v50 ( V50 no Recommend for diagnostic application ) BLACK
2mm, 5/64 , 4.9mm 40Mpa ,20mm LP:78 / 2mm 5/64, 4.9 ,63Mpa, 20mm LP:79
-0.1-120Mpa (-1~ +1200bar )
2240D-025V32 BLUE Two Spiral layers
4.0mm, 7.7mm , 120Mpa, 75mm 0.10Kg/m LP: 197.00
-0.1-220Mpa (-1~ +2200bar )
2440D-025V32 BLUE Four Spiral layers
3.9mm, 10.4mm , 220Mpa（550MPa）, 100mm, 0.21Kg/m LP: 415.00
Advace Use Left Thread Style
-0.1-280Mpa (-1~ +2800bar )
2640D-025V32 BLUE Six Sprial layers of Max
3.9mm ,12.0mm ,280Mpa( 700Mpa), 140mm, 0.29Kg/m LP: 1057.00
-0.1-300Mpa (-1~ +3000bar )
2740D-025V16 YELLOW Six Sprial layers of Max
4.0mm, 12.0mm , 300Mpa( 780Mpa), 120mm, 0.40Kg/m LP : 795.00
Advace Use Left Thread Style
-0.1-400Mpa (-1~ +4000bar )
2840D-03V34 RED Eight Spiral layers of maximum
4.5mm, 15.0mm , 400Mpa( 800Mpa), 200mm, 0.66Kg/m LP: 1365.00
Advace Use Left Thread Style
